£2,762.00
| Pack Size | 10 |
| Cantilever Length Range um | 10 |
| Cantilever Length um | 140 |
| Cantilever Number | 1 rectangular |
| Cantilever Thickness Range um | 0.5 |
| Cantilever Thickness um | 5 |
| Cantilever Width Range um | 5 |
| Cantilever Width um | 50 |
| Chip Size mm | 3.6x1.6x0.3 |
| Force Constant Max N/m | 95 |
| Force Constant Min N/m | 25 |
| Force Constant Typical N/m | 50 |
| Material | Single Crystal Silicon, N-type, 0.01-0.025 Ohm-cm, Antimony doped |
| Reflective Side Coating | None |
| Resonant Frequency Max khz | 400 |
| Resonant Frequency Min khz | 200 |
| Resonant Freq Typical khz | 300 |
| Tip Curvature Radius N/m | Typically 35nm |
